VECV Diesel GENSET 50 kVA

Overview of PRODUCT
50 KVA, Three Phase, 415 Volt, 50 Hz, 0.8 P.F.
POWER Engineering India Pvt Ltd Make Silent Water Cooled Diesel Generator Set Model No VE-50 comprising of Eicher engine model Eicher-E483TCI. 4 No of Cylinders Engines developing 65 HP, STAMFORD alternator rated at 50 KVA, 415 Volt.
Fuel Consumption at 90% Load = 6.5 Liters / Hours

Diesel Generating Sets
Better Design. Better Aesthetic. Better Value
Diesel Genset Range: 30kVA to 160kVA
VE Commercial Vehicles Ltd design and manufactures EICHER brand Automotive & Non-Automotive Engines with modern technology which is already established and known for high reliability, consistent quality and high-fuel efficiency. The Engines and Gensets are also exported to regions like Europe, Middle East, Africa & SAARC Nations.

EICHER POWERES GENSET TECHNICAL SPECIFICATION
Genset Model VE-50
Genset RatingKVA / kWe50 / 40
Current AmpAmps70 A
ENGINE TECHNICAL DETAILS
Engine Make EICHER
Engine Model EE483TCI
Electric SystemVolt12 V DC
Lube. Oil change PeriodHours500
Battery CapacityAH100AH
ALTENATOR TECHNICAL DETAILS
Alternator Make STAMFORD
Alternator Type SELF REGULATED/SELF EXCITED/BRUSHLESS
Type of Insulation IP 23, Class H
No. of Phase / VoltageVolt230 V Single phase or 415 V Three Phase
CONTROL PANEL TECHNICAL DETAILS
Control Panel Model MANUAL (Standard) Panel  With DSC Controller DSC4520
Type of Panel MANUAL (Standard) / Auto Mains Failure (Optional)
Make of Controller Deep-sea/Equivalent Reputed make
Location Mounted Inside Acoustic Enclosure
ACOUSTIC ENCLOSURE TECHNICAL DETAILS
Type of Canopy Outdoor Type, Ready to use – (CPCB-II Complaint)
Noise LeveldB75 dB at 1 Meter
Fuel Tank CapacityLiters130 Liters
Fuel Tank Location Mounted at base Inside Acoustic Enclosure
Genset With Acoustic Enclosure WeightKgs1400
Low Operating Cost :
# Remarkable Fuel Economy with Unmatched Engine Protections: EICHER is the most preferred engine in terms of fuel economy & it saves fuel in the range of 10%-15% over most of the other Engines.
# Very Economical Parts Prices: Low cost of maintenance
# Longer Service Interval: 500 Hours or 12 Months for Lub. Oil, Oil Filter & Fuel Filter.
# No Running-In Period: Even First Service Interval is 500 Hours/12 Months.
High Reliability :
# Compact size: Engine Ideal for roof top installation & helps saving land space.
# Air filter Choke indication: Provide safety indication for chocking of Air Filter.
# Starter Motor with Thermal cut off: Cut off starter motor in case of over starting.
# In-Built Oil Cooler: Suitable for Continuous Operation and Lower Lubricating Oil Consumption.
# Bypass Filter: Secondary Filtration system, provide filtration in case of chocking of primary filter.
# Piston Cooling Jet: provide cooling to piston at high temperature. Lower Break Down & higher reliability
# Extremely Low Vibration: Sculpted/Ribbed block for high rigidity which results to Lower vibration and Lower wear & tear.
# Robust Engine: Used in toughest applications like Construction Equipment, Material Handling, Marine, Agro and Pumping.
Service Efficiency:
# Easy Serviceability: Superior Accessibility of all Service points.
# Easy Spares Availability.
# Commonality of Spare Parts: Most of Spare parts used are common across the range.
# On Site Service Support: Proven technology will ensure that product support is available close by, without waiting for a specialist. EICHER Branded diesel engine does not require any complex or specialized tools for maintenance.
Best Performance:
# Quick Starting & smooth running    # Excellent Block Loading Capacity
# Excellent & unmatched fuel Efficiency    # Longer Product Life Cycle.

Salient Features:
# Compact Size
# Highest Efficiency in its class,
# Better Response Time and allows faster recovery of stabilized rated voltage
# Excellent Motor starting capability in the range of DG sets
# Ensure constant Voltage operation even at 5% reduced speed band.

Microprocessor Controlled:
A microprocessor based Controller is being provided to the generator with self -diagnostic & self-management system.
Salient Features:
It measures, monitor, control & operate all the required electrical mechanical parameters.
# User friendly LCD display.
# Logs last 50 Fault codes helps operator/service personal for troubleshooting.
# Safeties with annunciation.
# Engine Safeties: High Water Temperature, Low Lub. Oil Pressure, Low
Fuel Level, Charging Failure, Radiator, Water Level, Air Filter Choke.
# Alternator Safeties: Under Voltage, Under Frequency,  Over Frequency, Overloading
Control Panel
# Standard Manual Panel / AMF Panel
# MS construction Control panel
# Suitable rating 3 Pole MCB/MCCB
# All critical parameters of Engine and Alternator are displayed on Micro-processor based controller.
# Indoor Type Mounting Inside Acoustic Enclosure (Standard Control Panel)
Optional Feature:
# Auto Mains Failure Panel          #  Remote Start / Stop Panel
# GPS Based system for Remote monitoring and controlling.
